SH-P15WL01
Industrial-grade Fanless 15.6” Multi-Touch Panel PC
- Intel® Whiskey Lake-U/UE Celeron®, Core™ i3/i5/i7 Processors
- 15.6-inch 10-point capacitive multi-touch
- IP65 front panel protection
- Storage scalability: 1 x M.2 2280 M key, SATA, and 1x M.2 2280 SSD (optional)
- I/O interfaces: 1x HDMI 1.4, 4x USB 3.2 Gen1, 1x RS232, 1x M.2 2280 M key (Supports SATA storage interface)
- Customized I/O options: DVI-I, VGA, RS232, USB 2.0, POAG, M.2 2280, wide voltage range board, external antenna, and so on.
- Supports H/W TPM 2.0
| System | |
| Processor | 8th Gen. Intel® Whiskey Lake Core i3-8145UE, i5-8265U, i5-8365UE, i7-8565U, i7-8665UE, Celeron® 4305UE |
| Memory | 2 x 260 pin SO-DIMM up to 64GB Dual Channel DDR4 2400MHz |
| Display and Touch Screen | |
| Display | 15.6” 1920x1080 Full HD LED with 10-Point Capacitive Multi-Touch |
| Brightness | 250/350 nits (default 350nits) |
| Graphics | |
| Chipset | Intel® UHD Graphics |
| Display Interface | Supports two independent displays 1 x HDMI 1.4b: (4K / 30fps) 1 x DVI-I: 1920 x 1080@60Hz (optional daughter board) 1 x VGA (optional daughter board) |
| Storage | |
| Storage | 1 x M.2 2280, M key (PCIe x4 or SATA, either one) Option: 1 x M.2 2280, M key, SSD SATA I/F, Slidable design 1 x M.2 2280, M key, SSD SATA I/F, Fixed design (Either one of above) |
| Audio | |
| Audio Codec | Realtek ALC6662 |
| Network | |
| Ethernet | 1 x RJ-45 Lan Intel® Gigabit Ethernet 1 x RJ-45 2nd Lan (optional) |
| WLAN | 1 x M.2 2230, M key with Realtek RTL8821CE 802.11a/b/g/n/ac + Bluetooth 5.0 with 2 internal antenna (default) / external antenna (optional) |
| I/O Interface | |
| LAN | 1 x RJ-45 Lan Gigabit Ethernet 1 x RJ-45 2nd Lan optional) |
| Serial Ports | 1 x RS-232(DB-9) 2 x RS-232/422/485 (DB-9) (RS-232 with power supply: ring in/ 5V (standard) & 12V ((with specific optional board) |
| USB | 4 x USB3.2 Gen 1 (Type A) |
| Audio | 1 x Line-out 1 x Mic-in |
| Power | |
| Adapter | 19V/4.7A 90W extenal adapter |
| Power | 9-36V DC-in (Optional wide range board) |
| Watchdog Timer | |
| Watchdog Timer | 255 Sec. |
| OS Support | |
| OS Support | Windows 10/11 64bit Linux 64bit |
| Mechanism | |
| IP Rating | IP65 Front Panel Protection |
| Mounting | VESA Mount 100 x 100 mm |
| Dimension (WxHxD) | 394 x 256 x 48.9 mm |
| Weight | 4.6kg |
| Environment | |
| Operating Temperature | 0 ~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Relative Humidity | 10% - 90% RH (non-condensing) |
| EMC | CE, FCC, CEC, BSMI |
| Safety | CB, cTUVus, BSMI |
| RF | EU, US, Taiwan |
P15WL01 is an industrial-grade panel PC that integrates a 15.6 -inch FHD TFT-LCD panel with True-Flat touch. Based on Intel® Whiskey Lake-U/UE processors, it can deliver reliable processing performance when multitasking. It is designed with abundant features such as fanless technique, IP-65 certified front bezel panel, and rich I/O interfaces, including USB 3.2 Gen1, RS232, HDMI 1.4 and M.2 2280 M key.
P15WL01 offers customized I/O configurations that perform integration with industrial production architecture. Furthermore, it also supports one Gigabit LAN and IEEE 802.11ac WiFi + Bluetooth 5.0 to meet diverse application needs for IoT applications. P15WL01 is suitable as a human-machine interface (HMI), process control, infotainment, and kiosk.
