SH-P21WL01
21.5 inch Industrial Panel PC. Fanless wide screen
- Supports a variety of Intel® Whiskey Lake-U Processors, from commercial to embedde
- 21.5 inch 10-point projected capacitive touchscreen
- IP65 front-panel waterproof protection
- I/O interfaces: 1x HDMI, 1x DVI-I, 4x USB 3.2 Gen1, 1x RS232, 2x RS232/422/485 (support Ring in and 5V power), 2x RJ-45
- Easy swap storage design for install and upgrade convenience
- With aux easy access rocker switch
- Supports H/W TPM 2.0
Product Specification
| System | |
| Processor | 8th Gen. Intel® Whiskey Lake-U Processors Intel® CoreTM i3-8145UE Processor, Dual Core, 4M Cache, 2.2GHz (3.9GHz), 15W (default) Intel® CoreTM i5-8265U, Quad Core, 6M Cache, 1.6GHz (3.9GHz), 15W (optional) Intel® CoreTM i5-8365UE, Quad Core, 6M Cache, 1.6GHz (4.1GHz), 15W (optional) Intel® CoreTM i7-8565U, Quad Core, 8M Cache, 1.8GHz (4.6GHz), 15W (optional) Intel® CoreTM i7-8665UE, Quad Core, 8M Cache, 1.7GHz (4.4GHz), 15W (optional) Intel® Celeron® 4305UE, Dual Core, 2M Cache, 2GHz, 15W (optional) |
| Memory | 2 x 260 pin SO-DIMM up to 64GB Dual Channel DDR4 2400MHz |
| Display and Touch Screen | |
| Display | 21.5” 1920x1080 FHD TFT LCD with 10-Point Capacitive Multi-Touch |
| Viewing Angle (H/V°) | 89 (left), 89 (right), 89 (up), 89 (down) |
| Brightness | 500nits |
| Contrast | 1000 :1 |
| Backlight Lifetime | 30,000 hrs |
| Graphics | |
| Display Interface | Supports two independent displays 1 x HDMI 1.4b (4K / 30fps) 1 x DVI-I: 1920 x 1080@60Hz (optional daughter board) |
| Storage | |
| Storage | 1 x M.2 2280, M key (PCIe NVMe / SATA) 1 x 2.5” SSD SATA 3.0 drive bay (Swappable, compatible 7mm) |
| Audio | |
| Audio Codec | Realtek ALC662 2-channel |
| Network | |
| Ethernet | 1x Intel® Gigabit Ethernet 1x Intel® GbE LAN or 2.5 GbE (optional) (Support Wake on Lan) |
| WLAN | 1 x M.2 2230, M key with Realtek RTL8821CE 802.11a/b/g/n/ac + Bluetooth 5.0 with 2 internal antenna (default) / external antenna (optional) |
| I/O Interface | |
| LAN | 1 x RJ-45 Gigabit Ethernet 1 x RJ-45 2nd Lan GbE or 2.5GbE (optional) |
| Serial Ports | 1 x RS-232 (DB-9) 2 x RS-232/422/485 (DB-9) RS232 with power supply :ring in/ 5V (standard) &12V (with specific optional board) |
| USB | 4 x USB3.2 Gen 1 (Type A) |
| Audio | 1 x Line-out 1 x Mic-in |
| Power | |
| Adapter | 19V/4.74A 90W external adapter |
| Power | 9-36V DC-in (Optional wide range board) |
| Watchdog Timer | |
| Watchdog Timer | 255 Sec. |
| OS Support | |
| OS Support | Windows 10/11 64bit Linux 64bit |
| Mechanism | |
| IP Rating | IP65 Front Panel Protection |
| Mounting | VESA Mount 100 x 100 mm |
| Dimension (WxHxD) | 543 x 334 x 49.9 mm |
| Weight | 7.6kg |
| Environment | |
| Operating Temperature | 0 ~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Relative Humidity | 10% - 90% RH (non-condensing) |
| EMC | CE, FCC, VCCI, CEC, BSMI |
| Safety | cTUVus, CB, BSMI |
| RF | US, EU, Taiwan |
P21WL01 is a high-value, sturdy Panel PC equipped with a 21.5-inch Full HD TFT LED with true-Flat PCAP touch. The unit is designed with Intel® Whiskey Lake-U technology to provide high-performance computing in a fan-less system for high durability and functionality. In addition to default I/O interfaces, to further enhance system flexibility as well as to increase the versatility in application, The P21WL01 allows users to select different I/O ports Combination for diverse industrial applications. The P21WL01 is suitable to deploy into factory automation, vending-machine, infotainment in a public building, hospitality & retail, transportation, and so on.
