I-AFL3-08A-BT

8.4" Industrial IP64 panel PC. Intel® Celeron® J1900 Processor

Anewtech-industrial-panel-pc-I-AFL3-08A-BT

Features

  • 8.4” light industrial interactive panel PC
  • 9 V ~ 30 V wide range DC input with lockable DC jack
  • Selectable AT/ATX power mode
  • Built-in speakers
  • One mSATA slot
  • IP64/IP65 compliant front panel
  • IEI One Key Recovery solution allows you to create rapid OS backup and recovery (suggested with over 4GB storage capacity)

Specification

Dimensions
Dimensions 233 x 175 x 50
Environment
Humidity 10% to 95% (non-condensing)
Operating Temperature -10°C~50°C
Safety & EMC CE/FCC
Storage Temperature -20°C~60°C
I/O Interface
Audio ALC892
Ethernet 2 x PCIe GbE by RTL8111E controller
LCD
Brightness (cd/m2) 450
Contrast Ratio 600:1
LCD Color 16.2M
Pixel Pitch (mm) 0.213 (H) x 0.213 (V)
Resolution 800 x 600 (4:3)
Size 8.4”
Viewing Angle (H-V) 160º / 140º
Power
Power consumption 12V@2A(Intel® J1900 CPU with 2GB 1333 MHz DDR3L memory)
Power Requirement 9 V ~ 30 V
System
CPU Intel® Celeron® J1900 (quad core, 2.0 GHz)
Memory Max. One 204-pin 2 GB 1333MHz single-channel, 2GB DDR3L SDRAM pre-installed (system max. 8GB)
Storage mSATA
Touch
Touch Controller EETI EXC3160
Touch Screen Projected capacitive type
Weight
Weight 0.8/2.44
I/O Interface
I/O Interface 1 x Reset Button
1 x Power Switch
1 x AT/ATX switch
1 x DC Input Jack (9-30V Lockable)
1 x LAN (Gbe)
2 x USB 3.0
2 x USB 2.0
1 x Audio (line-out)
1 x RS-232 (RJ45 connector)
1 x RS-422/485 (DB-9 connector)

Ordering Information

Item Description
AFL3-08A-BT-J1/PC/2G-R10 8.4" 450cd/m² SVGA fanless panel PC with Intel® Celeron® J1900 quad core 2 GHz, 802.11 a/b/g/n/ac wireless module, projected capacitive touch screen, 2GB DDR3L RAM,R10
