15-inch I-Series 3 Slate with Intel
15.6" Intel® Pentium® Processor J6426. OS options include: Windows, ChormeOS Flex and Linux
Built with the reliability-tested performance and security of Intel 11th Generation processors, integrated Trusted Platform Modules and the Windows 10 operating system, the I-Series 3 Slate delivers the dependability businesses need.
- OS options include: Windows, ChormeOS Flex and Linux
- Modular design for flexible mounting in portrait, landscape and table-top orientations
- Extend connectivity from the display to your accessories with the I/O hub
Datasheet
Product Specification
Built to be one of the thinnest commercial-grade fixed tablet form factors, the I-Series Slate delivers a 15.6-inch Full HD interactive display, powerful Intel processor and your choice of Windows, Chrome and Linux (SuSE, Ubuntu and Red Hat). Backed by reliable, enterprise-grade security and performance, the I-Series offers a modular platform with versatility to fit almost any application - from point-of-sale and interactive signage to self-service and automation controls.
| Part Number(s) | No OS - E983676 Win 10 - E983895 |
| Enclosure Color | Dark Gray |
| Touch Technology & Capacity | PCAP (TouchPro® Projected Capacitive) - 10 Touch |
| Processor | Intel Elkhart Lake J6426 |
| Graphics | Intel UHD Graphics |
| BIOS | AMI |
| Memory (RAM) | 8GB 3200MHz DDR4 SO-DIMM on 1 slot (Expandable to 32GB maximum on 1 slot) |
| Storage | 128GB M.2 NVME SSD 72 TBW GB equals one billion bytes when referring to storage capacity. Accessible capacity may be less. |
| TPM | 2.0 |
| Diagonal Size | 15.6'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
| Active Area | 13.55" x 7.62" / 344.2 mm x 193.5 mm |
| Resolution | 1920 x 1080 @ 60Hz |
| Number of Colors | 16.2 million |
| Brightness (typical) | LCD panel: 300 nits TouchPro PCAP: 255 nits |
| Response Time-total (typical) | 25 msec |
| Contrast Ratio | 1000:1 |
| Viewing Angle | Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total |
| Webcam | 8MP Max Resolution: 1920x1080 30fps Auto Focus |
| I/O Ports | Display Head Interface: USB-C Connector Supports USB 2.0/3.0, DP output (Requires 20V/20W USB-C Power Delivery 2.0 if not using IO Hub for power) I/O Hub: DC Input 4 x USB-A 3.0 RJ45 Ethernet LAN (Gigabit) (wo Wake on Lan at S5 support) |
| Wireless | 802.11 a/b/g/n/ac/ax 2.4GHz, 5GHz and 6GHz |
| Bluetooth | Bluetooth 5.2 |
| Antenna | 2T2R design |
| Microphone | Digital Microphone |
| Speakers | 2 x 2W internal speakers |
| OS | No OS Windows 10 IoT Enterprise LTSC 64-bit |
| Languages | Windows 10 - 36 Language groups |
| Power Supply | External 19VDC universal-type power supply brick AC input voltage: 100-240 VAC Input frequency: 50-60 Hz Maximum output power: 65W |
| Power Consumption (Typical) | ON: 30W SLEEP: <2.0W OFF: <0.5W |
| Dimensions | Without VESA Adapter: 14.3" x 8.8" x 0.6" / 362.8 mm x 223.4 mm x 15.3 mm With VESA adapter: 14.3" x 8.8" x 0.8" / 362.8 mm x 223.4 mm x 20.2 mm |
| Shipping Box Dimensions | 18.11" x 12.64" x 7" / 460 mm x 321 mm x 178 mm |
| Weight (Unpackaged) | 3.53 lbs / 1.6 kg |
| Weight (Packaged) | 8.81 lbs / 4 kg |
| Operating Temperature | 0°C to 35°C / 32°F to 95°F |
| Storage Temperature | -20°C to 60°C / -4°F to 140°F |
| Humidity | Operating: 10% to 90% Storage: 0% to 95% (38.7°C max wet bulb temperature) |
| Energy Star | Energy Star 8.0 |
| Regulatory approvals and declarations | UL/cUL, FCC, CE, CB, NOM, RCM, VCCI, Argentina S-Mark, CCC, SRRC, ANATEL, UKCA |
| Real-Time Clock | CR2450 lithium metal battery |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | 75mm VESA mount |
| Warranty | 3-year |
| Extended Service Options | 4 year warranty coverage - Elo P/N: E819598 5 year warranty coverage - Elo P/N: E819795 3 year warranty coverage + AUR - Elo P/N: E820186 4 year warranty coverage + AUR - Elo P/N: E820388 5 year warranty coverage + AUR - Elo P/N: E820582 |
| What's in the Box | I Series Slate IO Hub North America Power Cord European Power Cord 65W Power Adapter Quick Installation Guide (QIG) |
