M-LUMA Pro A380 Quad
Standard single slot PCIe Gen4x 16 (x8 electrical) quad-output graphics card
Drive two 8K displays—or two 5Kp120 displays—or up to four synchronized high-resolution displays or projectors from a single Matrox LUMA Pro Series graphics card. A single-slot PCIe® 4.0 x8 card with four native Mini DisplayPort™ 2.0 connectors, A380 Quad delivers superior graphics performance for today’s multi-display video wall and digital signage applications.
For OEMs, system integrators, AV installers, and developers looking to create custom control functions, we also offer a complete range of video wall software, APIs, SDKs, and libraries. Matrox LUMA Pro Series is powered by Intel® Arc™ graphics.
With up to 6 GB of graphics memory, A380 Quad graphics card brings superior video playback and performance to a wide variety of video wall applications.
Drive multi-display IP-based video wall applications
LUMA Pro Series allows you to create powerful IP-based video walls with fewer components and smaller systems with the built-in MURA SDK media codec engine.
| Part number | LUMA-A380P |
|---|---|
| Bus type | PCIe 4.0 x 16 (x8 electrical) |
| Number of video outputs | 4 |
| Video output connectors | 4x DisplayPort |
| DisplayPort specification | 2.0 UHBR10 |
| Maximum number of cards in a system | 4 |
| Performance | |
| Maximum resolution | 2x 8K60/5K120 or 4x 5K60 HDR 12b |
| Bit depth and color space | Up to 36 bpp (Bits per Pixel) YCbCR 4:4:4 YCbCR 4:2:0 RGB |
| Memory | 6GB GDDR6 |
| GPU | Intel® ArcTM A380E |
| Multi-stream audio | High-definition audio streams on four digital ports simultaneously |
| Additional features | |
| DisplayPort features | VESA DSC 1.1, and Adaptive Sync |
| HDCP compliance | 2.3 |
| Power connector | - |
| Board-to-board framelock | Max of 4 cards |
| Supported graphics API | DirectX 12 Ultimate, OpenGL 4.6, OpenCL 3.0, Vulkan 1.3, oneAPI and OpenVINO |
| Hardware video encode/decode | H264/H265/AV1/VP9 |
| Hardware | |
| Form factor | Standard Height Single Slot |
| Dimensions | Length: 25.38 cm (9.99”) Height: 12.68 cm (4.99”) |
| Bracket | Standard Height |
| Environmental & Power consumption | |
| Cooling | Active |
| Power consumption | 75W |
| Operating temperature | 0 to 45 oC (32 to 113 °F) |
| Regulatory compliance | CE (EU) Class A, FCC (US) Class A, ICES-003 (Canada) Class A, KC (S. Korea) Class A, RCM (Aus/NZ) Class A, UKCA (UK) Class A, CSA/UL 62368-1, IEC 62368-1 |
| Environmental compliance | EU RoHS, China RoHS, REACH, WEEE |
| Software & API | |
| Matrox PowerDesk for Windows | Yes |
| Mura Developer tools | Yes |
| Operating systems | Windows 10 64-bit & LTSC (version 21H2 and up) / Windows 11 up to 24H2 and 64-bit LTSC (version 24H2) |
| System requirements2 | Single available PCIe 4.0 (or newer) x8 slot Intel Core Processor from 10th Gen to 14th Gen, Intel Xeon W-35xx/25xx/34xx/24xx processor for workstations Resizable BAR (reBAR) or Smart Access Memory (SAM) |
