AD-AIMB-2710
Mini-ITX Motherboard supports Intel® Core™ Desktop Processors (LGA1851), Q870/H810 PCH
- Intel® Core™ Ultra Processor (LGA1851), Up to 24 Core. Support Q870/H810 PCH
- Dual channel DDR5 6400MT/s, max. 96GB with two CSODIMM
- Super Speed I/O: PCIe x16 Gen5 (32GT/s), USB 3.2 Gen2x1 (10Gbps), 2.5 GbE
- Rich expansion: M.2 M key for NVMe SSD, M.2 E key for wireless, 2 SATA and 1 USB4/Thunderbolt™4
- 12-24V DCin + ATX 5VSB Power Input
- Windows 11 LTSC & Ubuntu 24.04 LTS; SUSI API and WISE-DeviceOn
Enhances AI and Hybrid Computing with Intel® Core™ Ultra Processors (Series 2) S-Series
AI-integrated desktop platform series: the Mini-ITX AIMB-2710 and Micro-ATX AIMB-589 are powered by Intel® Core™ Ultra Processors (Series 2) S-Series, featuring the first desktop processor with an integrated NPU, delivering up to 36 TOPS for superior AI acceleration.
Designed for data visualization and image analysis, both models offer PCIe Gen5 support for high-performance GPU cards and feature 6400MHz DDR5 memory, USB4 Type-C, multiple USB 3.2 Gen2 and 2.5GbE LAN ports for fast and accurate data transmission in real time.
The AIMB-2710 and AIMB-589 excel in high-speed computing and AI-driven performance, making them ideal for applications such as medical imaging, automated optical inspection, and semiconductor testing. Backed by comprehensive software support, these platforms are engineered for the next wave of AI innovation.
