15-inch I-Series 5 Slate with Android
15.6-inch Full HD interactive system, complete with Android 14 OS, Qualcomm processor and an I/O hub
- Create a sleek point of sale system by pairing with the Z10 & Z30 POS Stands
- Qualcomm 6490 chipset offers a fused AI accelerator providing performance of up to 12 TOPS
- Enterprise-Grade Support - OS 360 security updates, seamless provisioning, OEMConfig and more
Elo's I-Series 5 Slate delivers a powerful 15.6-inch Full HD interactive system, complete with Android 14 OS, Qualcomm processor and an I/O hub. Built to be one of the thinnest commercial-grade fixed tablet form factors, the I-Series 5 Slate delivers a stunning design, enhanced durability, increased touch accuracy and brilliant display clarity.
| Part Number(s) | E540697 |
| Enclosure Color | Dark Gray Metallic |
| Touch Technology & Capacity | PCAP (TouchPro® Projected Capacitive) - 10 Touch |
| Processor | Qualcomm Snapdragon QCS6490 |
| Memory (RAM) | 8GB |
| Storage | 64GB |
| OS | Android 14 with Google Play Services (AOSP capable) Upgrade to Android 16 and planned upgrade to Android 18 are available with an OS 360 subscription |
| Diagonal Size | 15.6'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
| Active Area | 13.55" x 7.62" / 344 mm x 194 mm |
| Resolution | 1920 x 1080 @ 60Hz |
| Number of Colors | 8-bit (16.7 million) |
| Brightness (typical) | LCD Panel: 350 nits TouchPro PCAP: 280 nits |
| Response Time-total (typical) | 20 ms |
| Contrast Ratio | 1000:1 |
| Viewing Angle | Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total |
| I/O Ports | Display Head Interface: USB-C Connector Supports USB 2.0/3.0, DP output (Requires 20V/20W USB-C Power Delivery 2.0 if not using IO Hub for power) I/O Hub: DC Input 4 x USB-A 3.0 (900mA) RJ45 Ethernet LAN (Gigabit) |
| Webcam | 8MP Max Resolution: 3200x2400 30fps Auto Focus |
| Wireless | 802.11a/b/g/n/ac/ax + Bluetooth 5.2 |
| Audio Ports | 2x built-in Digital Microphones |
| Speakers | 2x 1W |
| Power Supply | AC input voltage: 100-240 VAC Input frequency: 50-60 Hz |
| Power Consumption (Typical) | On: 8.5W Off: 0.4W Sleep: 3W |
| Dimensions | With VESA: 14.6" x 8.7" x 0.6" / 370.3 mm x 221.3 mm x 15.1 mm |
| Shipping Box Dimensions | 17.4" x 12.2" x 6.1" / 445 mm x 308 mm x 160 mm |
| Weight (Unpackaged) | 3.44 lbs / 1.56 kg |
| Weight (Packaged) | 7.74 lbs / 3.51 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 50°C / -4°F to 122°F |
| Humidity | Operating: 20% to 80% Storage: 10% to 90% |
| Regulatory approvals and declarations | UL/cUL (US) FCC (US) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| Supported Countries | Canada, USA, Australia, Japan, New Zealand, Austria, Belgium, Czech Republic, Denmark, France, Germany, United Kingdom, Hungary, Italy, Netherlands, Poland, Portugal, Romania, Spain, Sweden, Switzerland, Turkey |
| Real-Time Clock | lithium coin cell battery |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | VESA 75 mm / Z-Hinge |
| Warranty | 2-year |
| OS Support | Bi-monthly Android security updates available with Elo OS 360 package. |
| Sealability | Touchscreen optically bonded to LCD |
| What's in the Box | I-Series 5 Slate IO Hub North American Power Cable European Power Cable 1x Power Brick 65W (E153026) Quick Install Guide 4 x M4x6 mm Panhead screws in a plastic bag |
| Optional Peripherals | 1302L Customer-facing Display (10 touch) – Elo P/N: E683595 (requires both the display mount kit E835969 and Elo 2ft USB-C cable E969524)) |
| Stands, Mounts & Kits | 65W Replacement Cable Kit (NA & EU power cables and power brick) – Elo P/N: E514304 Z10 POS Stand (75mm VESA) - Elo P/N: E767159 |
