A-SPC-1542
15" 13th Generation Intel® Core™ 3/5/7 Processors Fanless Stainless Steel Chassis Touch Panel PC with Full IP-66 & IP-69K
- Intel® 13th Gen Raptor Lake-PS Core™ 3/5/7 Processor (LGA1700 Socket Type)
- Projective capacitive touchscreen full flat design
- Waterproof power button
- Rich and swappable I/O, 1 x LAN, 2 x USB, 1 x COM by M12 8-pin(male) with waterproof cover and chain
- IP66 air pressure relief valve
- 1x 262-pin DDR5 4800MHz SO-DIMM socket, supports up to 32GB
- Wide range DC in +19V ~ +24V
- Wide temperature -10°C ~ 50°C
- Full system IP66, IP69K
- Multiple OS support (Win10/11, Linux)
- Optional WiFi/BT with waterproof antenna
Datasheet
Product Specification
| System Information | |
| Processor | Intel® 13th Gen Raptor Lake-PS Core™ 3/5/7 Processor (LGA1700 Socket Type) |
| System Memor | 1x 262-pin DDR5 4800MHz SO-DIMM socket, supports up to 32GB |
| I/O Chipset | EC ITE IT8883FN-I |
| Watchdog Timer | H/W reset, 1sec. ~ 65535sec./1sec.step |
| H/W Status Monitor | Monitoring CPU & System Temperature and Voltage |
| TPM | TPM 2.0 |
| SBC | HID-2340 |
| CPU Cooler (Type) | Fanless heatsink |
| Other | 1 x WiFi with waterproof antenna (optional) |
| Expansio | |
| Expansion | 1 x M.2 Key B 3042/3052/2280 with 1 x PCI-e x2 & 1 x USB 3.0/2.0 signal 1 x M.2 Key E 2230 support WiFi module |
| Storage | |
| Storage | Default with 128GB SSD |
| Other Storage Device | 1 x M.2 Key M 2280 (PCI-e x4) slot for storage (Optional) |
| Displa | |
| Graphic Chipset | Intel® Graphics |
| Spec. & Resolution | LVDS: Max. Resolution 1920x1080 @ 60Hz eDP: Max. Resolution 1920 x 1080 @ 60Hz |
| Audio | |
| Audio Codec | Realtek ALC888S |
| Ethernet | |
| LAN Chipset | 1 x Intel I225LM Gigabit Ethernet |
| Ethernet Interface | 10/100/1000 Base-Tx GbE compatible |
| Power Requirement | |
| DC Input | +19V ~ +24V |
| ACPI | Single power ATX support S0, S3, S4, S5 and ACPI 3.0 compliant |
| Software Support | |
| OS | Win10 / 11, Linux |
| Certificatio | |
| Certification Information | CE / FCC Class A |
| Panel | |
| LCD Size | 15", 4:3 |
| Display Type | XGA |
| Resolution | 1024 x 768 |
| Pixel pitch | 0.297mm(H) x 0.297mm(V) |
| Luminance | 300 cd/m2 |
| Contrast ratio | 2000 |
| Viewing angle | 88 (U), 88 (D), 88(L), 88 (R) |
| Response time | 16 ms |
| Backlight | LED |
| Touch Type | Projective capacitive multi-touch up to 10 points |
| Touch Light Transmission | 85% |
| Touch Controller | ILITEK COF touch |
| External I/O | |
| USB Port | 2 x M12 8-pin (male) for 2 x USB 2.0 with waterproof cover and chain |
| LAN Port | 1 x RJ-45 8-pin (male) for LAN with waterproof cover and chain |
| COM Port | 1 x M12 8-pin (male) for COM (RS-232/422/485) with waterproof cover and chain |
| Internal I/O | |
| SATA | 1 x SATA III |
| System Control | |
| LED Indicator | HDD LED, power LED |
| Mechanical & Environmental | |
| Operating Temp. | -10°C ~ 50°C (14°F ~ 122°F), by flow = 0.5 |
| Storage Temp. | -20°C ~ 60°C (-4°F ~ 140°F |
| Operating Humidit | 40°C @ 95% Relative humidity, non-condensin |
| Dimension (W x L x H) | 393 x 315.8 x 49mm |
| Weight | 7.9Kg |
| Vibration Test | With SSD/mSATA : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis |
| Shock Test | With CF/SSD : 10Grms, IEC 60068-2-27, half sine, 11ms |
| Drop Test | ISTA 2A, IEC-60068-2-32 Test:Ed |
| IP Rating | Whole system IP69K, IP66 |
| Mounting Kit | Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm |
| Power Mode | AT/ATX (ATX is default) |
| System Fan | Fanless |
| Construction - Front | Stainless steel |
| Construction - Rear | Stainless steel |
| Component | |
| Adapter | Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 90W adapter (24V @ 3.75A adapter) AC-DC adapter (need waterproof M12/4pin-D2.5 DC Jack-plug 200cm cable for M12 DC in connector |
Ordering Information
| SPC-1542-100-A1R | 15" 1024 x 768 Full IP-66 Stainless Steel panel PC/PCap/IP-69K/ Intel 3-100UL/ 8GR/128GSSD/5M12/LAN/2x2USB/COM/DCin)/VentValve/HID-2340/without Adapter |
| SPC-1542-120-A1R | 15" 1024 x 768 Full IP-66 Stainless Steel panel PC/PCap/IP-69K/ Intel 5-120UL/ 8GR/128GSSD/5M12/LAN/2x2USB/COM/DCin)/VentValve/HID-2340/without Adapter |
