SYS-111AD-HN2

Intel Single Socket LGA-1700 support 12th & 13th Gen, 200W AC-DC PWS, 1U edge Server

Anewtech Systems Supermicro Singapore Supermicro Servers SuperServer SYS-111AD-HN2 Rackmount Server Supermicro Computer Embedded IoT Server SYS-111AD-HN2
  • Single Socket LGA-1700 support 12th & 13th Gen Core i9/i7/i5/i3 Processor,up to 80W
  • 4x DIMMs; Up to 128GB Unbuffered ECC/non-ECC UDIMM
  • 1x PCIe Gen5 x16 HHHL slot
  • 2 Hot-swap 2.5" SATA3 drive bays
  • 4x 40x28mm 4-pin PWM fans
  • 200W Low Noise AC-DC power supply with PFC
  • Rear-access I/O: 2x 2.5GBased-T, 1x Dedicated IPMI, 4x USB3.2, 1x VGA, 1x DVI-D, 2x DP,1x HDMI 2.0b
Datasheet
SYS-111AD-HN2.pdf
Product Specification
Anewtech-Systems Supermicro Singapore Supermicro Servers IoT-Server-Supermicro-SYS-111AD-HN2-SuperServer Supermicro Computer Embedded IoT Server Supermicro Singapore
Product SKUsSuperServer SYS-111AD-HN2 (Black)
MotherboardSuper X13SAZ-F
Processor
CPUSingle LGA-1700
12th/13th Gen Core i9/i7/i5/i3 Processor
System Memory
MemoryMemory Capacity: 4 DIMM slots
Up to 128GB: UDIMM
Memory Type: 4000MHz DDR5 UDIMM
Memory Voltage1.1 V
Error DetectionECC/Non-ECC
On-Board Devices
SATASATA3.0
ChipsetSystem on Chip
Network Connectivity2x 2.5GbE BaseT with Intel® I225-LM
IPMISupport for Intelligent Platform Management Interface v.2.0
IPMI 2.0 with virtual media over LAN and KVM-over-LAN support
Input / Output
SATA2 SATA (6Gbps) port(s)
LAN2x 2.5GbE
USB4 USB 3.2  Gen2 port(s) (4 USB)
Video1 VGA port(s)
Others1x DVI-D
1x HDMI 2.0b
1x Line Out
1x Mic In
2x DP 1.4
Management
SoftwareIPMI 2.0
Power ConfigurationsACPI Power Management
Power-on mode for AC power recovery
PC Health Monitoring
TemperaturePlatform Environment Control Interface (PECI) 3.0 support
SuperDoctor® 5
System resource alert via SuperDoctor®5
Chassis
Form Factor1U Rackmount
ModelCSE-510FT-203B
Dimensions and Weight
Height1.7" (43mm)
Width17.2" (437mm)
Depth11.3" (287mm)
Package6.1" (H) x 25.4" (W) x 19.8" (D)
WeightNet Weight: 10 lbs (4.54 kg)
Gross Weight: 14.1 lbs (6.4 kg)
Available ColorBlack
Front Panel
ButtonsPower On/Off
UID button
LEDsHDD activity
LAN1 activity
LAN2 activity
Power status
System information
Expansion Slots
PCI-Express (PCIe)1 PCIe 5.0 x16 HHHL slot(s)
Drive Bays / Storage
Hot-swap2x 2.5" hot-swap SATA/PCIe drive bays
M.21 M.2 NVMe
M-Key, 2280/22110
System Cooling
Fans4x 4-PIN PWM 40x28mm Fan(s)
Power Supply1U 200W Multi-output power supply Gold level w/20pin
Dimension (W x H x L)76.5 x 40.3 x 192.8 mm
AC Input200W: 100-240Vac / 2.6A Max / 50-60Hz
+12VMax: 16A / Min: 0A (100Vac-240Vac)
Operating Environment
Environmental Spec.Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Non-operating Relative Humidity: 5% to 95% (non-condensing)
NoteAcceptable AC Input Voltage: 100-240Vac / 5.5A-10A / 50-60Hz
Operating Temperature: Continuous 0°C ~ 40°C (32°F ~ 104°F), Short term -5°C ~ 55°C (23°F ~ 131°F)
