EN50155 Ethernet Switch
| Model Sort ascending | Image | Product Description | Datasheet |
|---|---|---|---|
| O-TXPS-141XT-M12-MV |
|
EN50155 5-port unmanaged PoE Ethernet switch with 4x10/100/500Base-T(X) P.S.E. and 1x10/100/500Base-T(X), M12 connector, 110VDC power input |
O-TXPS-141XT-M12-MV.pdf |
| O-TXES-180-M12 |
|
EN50155 8-port unmanaged Ethernet switch with 8x10/100/500Base-T(X), M12 connector |
O-TXES-180-M12.pdf |
| O-TXES-150-M12 |
|
EN50155 5-port unmanaged Ethernet switch with 5x10/100/500Base-T(X), M12 connector |
O-TXES-150-M12.pdf |
| O-TSPL-101GT-M12 |
|
EN50155 Industrial 1-port Gigabit High Power PoE Splitter, IEEE802.3at standard compliant, 12VDC output, M12 connector |
O-TSPL-101GT-M12.pdf |
| O-TRGPS-9084GT-M12X-BP2-MV |
|
EN50155 Industrial 12-port rack mount managed Gigabit Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. and 4x10/100/1000Base-T(X), M12 Connector and 2xbypass included |
O-TRGPS-9084GT-M12X-BP2-MV.pdf |
| O-TPS-3162GT-M12X-BP1-MV |
|
EN50155 18-port managed PoE Ethernet switch with 16x10/100Base-T(X) P.S.E. and 2x10/100/1000Base-T(X), M12 connector and 1xbypass included, 110VDC power input |
O-TPS-3162GT-M12X-BP1-MV.pdf |
| O-TPS-3082GT-M12X-BP1-MV |
|
EN50155 10-port managed PoE Ethernet switch with 8x10/100Base-T(X) P.S.E. and 2x10/100/1000Base-T(X), M12 connector and 1xbypass included, 110VDC power input |
O-TPS-3082GT-M12X-BP1-MV.pdf |
| O-TGXS-1080-M12 |
|
EN50155 8-port unmanaged Gigabit Ethernet switch with 8x10/100/500/1000Base-T(X), M12 connector |
O-TGXS-1080-M12.pdf |
| O-TGXPS-1080-M12-MV |
|
EN50155 8-port unmanaged Gigabit PoE Ethernet switch with 8x10/100/500/1000Base-T(X) P.S.E., M12 connector, 110VDC power input |
O-TGXPS-1080-M12-MV.pdf |
| O-TGXPS-1080-M12-BP2-24V |
|
EN50155 8-port unmanaged Gigabit PoE Ethernet switch with 8x10/100/500/1000Base-T(X) P.S.E., M12 connector and 2xbypass included, 24VDC power inputs |
O-TGXPS-1080-M12-BP2-24V.pdf |
| O-TGXPS-1080-M12-24V |
|
EN50155 8-port unmanaged Gigabit PoE Ethernet switch with 8x10/100/500/1000Base-T(X) P.S.E., M12 connector, 24VDC power inputs |
O-TGXPS-1080-M12-24V.pdf |
| O-TGS-9200-M12 |
|
EN50155 20-port managed Gigabit Ethernet switch with 20x10/100/1000Base-T(X), M12 connector |
O-TGS-9200-M12.pdf |
| O-TGRS-T120-M12X-BP2-WV |
|
EN50155 12-port managed router switch with 12x10/100/1000Base-T(X) ports, X-coding M12 connector and 2xbypass included, wide-range power input |
O-TGRS-T120-M12X-BP2-WV.pdf |
| O-TGPS-9164GT-M12X-BP2-MV |
|
EN50155 20-port managed Gigabit PoE Ethernet switch with 16x10/100/1000Base-T(X) P.S.E. and 4x10/100/1000Base-T(X), X-coded M12 connector and 2xbypass included, 110VDC power input |
O-TGPS-9164GT-M12X-BP2-MV.pdf |
| O-TGPS-9084GT-M12X-BP2-MV |
|
EN50155 12-port managed Gigabit PoE Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. and 4x10/100/1000Base-T(X), X-coded M12 connector and 2xbypass included, 110VDC power input |
O-TGPS-9084GT-M12X-BP2-MV.pdf |
| O-TGPS-9080-M12A-MV |
|
EN50155 8-port managed Gigabit PoE Ethernet switch with 8x10/100/1000Base-T(X) P.S.E. with A-coded M12 connector, 110VDC power Input |
O-TGPS-9080-M12A-MV.pdf |
| O-TES-W9124GT-M12X-BP2-24V-IP54 |
|
EN50155 16-port managed Ethernet switch with12x10/100Base-T(X) and 4x10/100/1000Base-T(X), X-coded M12 connector and 2xbypass included, 24VDC power inputs, IP-54 grade |
O-TES-W9124GT-M12X-BP2-24V-IP54.pdf |
| O-TES-3162GT-M12-BP1 |
|
EN50155 18-port managed Ethernet switch with 16x10/100Base-T(X) and 2x10/100/1000Base-T(X), M12 connector and 1xbypass included |
O-TES-3162GT-M12-BP1.pdf |
| O-TES-3080-M12-BP2 |
|
EN50155 8-port managed Ethernet switch with 8x10/100Base-T(X), M12 connector and 2xbypass included |
O-TES-3080-M12-BP2.pdf |
| O-TES-3080-M12 |
|
EN50155 8-port managed Ethernet switch with 8x10/100Base-T(X), M12 connector |
O-TES-3080-M12.pdf |
