A-ARC-18W42
18.5" 13th Generation Intel® Core™ 3/5/7 Processors Fanless Rugged Touch Panel PC with IET Expansion
- Intel® 13th Gen Raptor Lake-PS Core™ 3/5/7 Processor (LGA1700 Socket Type)
- Full flat front panel with projected capacitive touch supports multi touch
- One 262-pin SODIMM socket max. up to 32GB DDR5 4800MHz
- 3 x USB3.2, 1 x USB2.0, 1 x USB Type C, 1 x COM
- Dual Intel Gigabit LAN
- 3 x M.2 slots (Key-B 2242/3052/2280, Key-E 2230, Key-M 2280)
- Support Wi-Fi / BT / 4G / 5G (by option)
- Wide voltage +12V ~ +24V input, ErP power
- Available expansion for audio, USB, COM, HDMI, MPCIe, GPIO, CAN bus
- IP65 compliant front panel, IP41 rear box
- With panel mount kits include
- TPM 2.0 function
- Fanless operation from -10°C ~ 50°C (14°F ~ 122°F)
Datasheet
Product Specification
| System Information | |
| Processor | Intel® 13th Gen Raptor Lake-PS Core™ 3/5/7 Processor (LGA1700 Socket Type) Intel® Core™ 3 processor 100UL (10M Cache, up to 4.50 GHz) Intel® Core™ 5 processor 120UL (12M Cache, up to 4.60 GHz) Intel® Core™ 7 processor 160UL (12M Cache, up to 5.20 GHz) |
| System Memory | 1 x 262-pin SODIMM socket max. up to 32GB DDR5 4800MHz |
| I/O Chipset | EC ITE IT8528E |
| Watchdog Timer | H/W reset, 1sec. ~ 65535min. and 1sec. or 1min./step |
| H/W Status Monitor | Monitoring CPU & system temperature and voltage |
| TPM | Onboard NuvoTon NPCT754AABYX support TPM 2.0 |
| SBC | HID-2340 SBC |
| CPU Cooler (Type) | Fanless heatsink |
| Other | 7 x Knockouts for antenna mounting *5 from rear cover + 2 from IET bracket |
| Expansion | |
| Expansion | 1 x M.2 Key B 3042/3052/2280 (PCIe, USB3, SATA) for 4G/5G/Capture Card 1 x M.2 Key E 2230 (PCIex1, USB2.0) for WIFI 1 x M.2 Key M 2280 (PCI-e x4) slot for storage 1 x 80-pin IET interface |
| Storage | |
| Storage | 1 x M.2 Key M 2280 (PCI-e x4) slot for storage) |
| Display | |
| Graphic Chipset | Intel® Raptor Lake-PS integrated graphics |
| Spec. & Resolution | HDMI: Max. Resolution 4096x2160 @ 24Hz (optional by IET module) |
| Audio | |
| Audio Codec | Realtek ALC888S |
| Speaker Output | 2 x 2W |
| Ethernet | |
| LAN Chipset | 1 x Intel® I225LM 2.5 Gigabit Ethernet 1 x Intel® I226LM 2.5 Gigabit Ethernet |
| Ethernet Interface | Intel® I225LM: 10/100/1000/2.5G Base-Tx GbE compatible Intel® I226LM: 10/100/1000/2.5G Base-Tx GbE compatible |
| Power Requirement | |
| DC Input | +12V ~ +24V |
| DC Input Connector | Lockable DC Jack (default) Optional for phoenix connector |
| ACPI | Single power ATX support S0, S3, S4, S5 and ACPI 3.0 compliant |
| Software Support | |
| OS | Win10 / Win11 / Linux |
| Certification | |
| Certification Information | CE / FCC Class A / VCCI |
| Panel | |
| LCD Size | 18.5", 16:9 |
| Display Type | FHD |
| Resolution | 1920 x 1080 |
| Pixel pitch | 0.213mm(H) x 0.213mm(V) |
| Luminance | 500 cd/m2 |
| Contrast ratio | 1200 |
| Viewing angle | 85 (U), 85 (D), 85 (L), 85 (R) |
| Response time | 35 ms |
| Backlight | LED |
| Touch Type | Projective capacitive multi-touch up to 10 points |
| Touch Light Transmission | 85% |
| Touch Controller | ILITEK(ILI2510) |
| External I/O | |
| USB Port | 3 x USB3.2, 1 x USB2.0, 1 x USB Type C |
| LAN Port | 2 x RJ-45 |
| COM Port | 1 x RS-232/422/485 |
| System Control | |
| LED Indicator | HDD LED, power LED |
| Mechanical & Environmental | |
| Operating Temp. | -10°C ~ 50°C (14°F ~ 122°F) |
| Storage Temp. | -20°C ~ 60°C (-4°F ~ 140°F) |
| Operating Humidity | 40°C @ 95% Relative humidity, non-condensing |
| Dimension (W x L x H) | 460 x 285.2 x 55.5mm |
| Weight | 4.6 Kg |
| Vibration Test | With SSD/M.2 SSD : 2Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30mins/axis |
| Shock Test | Operating with SSD/M.2 : MIL-STD-810G, method 516.6, procedure I, functional shock=20G |
| Drop Test | ISTA 2A, IEC-60068-2-32 Test:Ed |
| IP Rating | Front panel IP65 Back cover IP41 |
| Mounting Kit | Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm Panel mount with mounting kits |
| Power Mode | AT/ATX (ATX is default) |
| System Fan | Fanless |
| Construction - Front | Die casting with cover lens |
| Construction - Rear | Black die casting |
| Component | |
| Adapter | Input: 100 ~ 240Vac/ 50 ~ 60Hz Output: 72W adapter (19V @ 3.78A adapter) AC-DC adapter |
Ordering Information
| Part No. | Description |
| ARC-18W42-100-B1R | 18.5" 1920x1080 Industrial Touch Panel PC, ErP Design, PCAP Multi Touch(ALC888S) 13th Gen Core™ 3 processor 100UL (10M Cache, up to 4.50 GHz)/2GLAN/1COM/4USB/TypeC/SPK/12~24V input/12V Adapter |
| ARC-18W42-120-B1R | 18.5" 1920x1080 Industrial Touch Panel PC, ErP Design, PCAP Multi Touch(ALC888S) 13th Gen Core™ 5 processor 120UL (12M Cache, up to 4.60 GHz)/2GLAN/1COM/4USB/TypeC/SPK/12~24V input/12V Adapter |
| ARC-18W42-160-B1R | 18.5" 1920x1080 Industrial Touch Panel PC, ErP Design, PCAP Multi Touch(ALC888S) 13th Gen Core™ 7 processor 160UL (12M Cache, up to 5.20 GHz)/2GLAN/1COM/4USB/TypeC/SPK/12~24V input/12V Adapter |
