I-PPC2-C17-EHL

17” Fanless Panel PC with Intel® Celeron® Processor J6412

Anewtech Systems Industrial Panel PC IEI Industrial Touch computer I-PPC2-C17-EHL
  • Intel® Elkhart Lake Platform
  • Dual M.2 (M.2 B Key & M.2 M Key) support
  • Anti-glare and Anti-UV PCAP
  • Support Gloved and Wet Hand Operation
  • Newly Designed Panel Mount Kit
Datasheet
Product Specification
Anewtech-Inudstrial-touch-panel-pc-PPC2-C17-EHL-iei
Anewtech-Systems-industrial-panel-pc-PPC2-C08-EHL-iei-touchscreen-panel-pc

The PPC2-C17-EHL heavy industrial panel PC is designed with rugged features to handle harsh work environments of any size. It is fanless, supports wide operating temperature from -10°C to 60°C, and provides features that resist vibration including 8GB on-board memory and NVMe storage.

Intel® Celeron® J6412 CPU is selected as the heart of the panel PC to deliver excellent performance at ultra-low power. The equipped 10-point P-CAP touchscreen with anti-glare/anti-UV coating and scratch resistance provides IP65 protection and supports gloved/wet hand operation, making the panel PC an ideal solution for Industrial Internet of Things (IIoT) applications.


System
Cooling method / System FanFanless
CPUIntel® Celeron® Processor J6412 1.5M Cache, up to 2.60 GHz / TDP 10W
On-board Memoryon-board dual-channel LPDDR4x 8GB
Storage1 x M.2 2280 M-key (PCIe Gen3 x2)
1 x 2.5” HDD/SSD drive bay
I/O Interface
Ethernet2 x 2.5GbE LAN via Intel® I225V
Expansion1 x M.2 2242/2280 B key (PCIe Gen3 x1 + USB 3.0)
1 x M.2 B key 2242/2280 (PCIe Gen3 x2 + USB 2.0)
Environment
Operating Temperature-10ºC ~ 60ºC
Safety & EMCCE, FCC Class A, UKCA
Humidity10% ~ 95%, non-condensing
Storage Temperature-20ºC ~ 60ºC
Physical Characteristics
ColorBlack
MountingVESA 75/100, Panel, Wall, Rack, Stand and Arm
Dimensions (LxWxH) (mm)408.40 x 341.40 x 61.80
Net Weight4.83 Kg
LCD
Size17” (5:4)
Resolution1280 (W) x 1024 (H)
Brightness (cd/m2)350 cd/m²
Contrast Ratio800:1
LCD Color16.7M
Pixel Pitch (mm)0.26 x 0.26
Viewing Angle (H-V)170°/160°
Backlight MTBF50,000 hours
Touch
Touch ScreenMulti-point projected capacitive type (anti-UV / anti-glare coating, support gloves)
Surface hardness: 7H
Touch ControllerEETI 80 series
Other Features
TPMIntel® Platform Trust Technology
I/O Interface
I/O Interface1 x RS-232/422/485 (by DB9)
4 x USB 2.0
1 x HDMI (up to 3840*2160 @30Hz)
2 x LAN -
LAN1: Intel® I225V 2.5GbE controller
LAN2: Intel® I225V 2.5GbE controller
1 x Reset Button
1 x Power Switch
1 x AT/ATX switch
1 x Clear CMOS Button
4 x RS-232 (by DB9)
2 x Power In -
1 x 12V-24V power jack
1 x Power terminal block (2-pin)
2 x USB 3.2 Gen2x1 (10Gb/s(Type A))
OS Support
OS SupportWindows 10 IOT
Linux
