EloPOS Z20
10" or 15" Android POS System with optional 10", 13" or 15" secondary display
- Available in 10" or 15" sizes with sleek edge-to-edge glass PCAP touchscreen
- Enterprise-Grade Support - Security updates, seamless provisioning, Elo Home, OEMConfig and more
- Integrated I/O hub & concealed cable routing simplify peripheral connectivity
- Easily add peripherals to the edge of the display with the Elo Edge Connect™
Datasheet
Product Specification
Built on Elo’s unified Android platform, the EloPOS Z20 delivers commercial-grade performance tailored for point-of-sale environments. Available with your choice of a 10- inch or 15-inch interactive display, the EloPOS Z20 features an integrated connectivity hub, concealed cable routing, and Android 14 OS, providing robust performance without compromising counter space.
For added flexibility, the flip-display design enables seamless transition from employee-facing to customer-facing interactions, supporting both fullservice and self-service applications. Start elevating your point-of-sale experience by with the EloPOS Z20, purpose-built for reliability, flexibility, and ease of integration.
| Part Number(s) | 10" Models: 10" EloPOS Z20, Black - E554932 + E539154 10" EloPOS Z20, White - E554932 + E539346 (MTO) 15" Models: 15" EloPOS Z20, Black - E767356 + E540294 15" EloPOS Z20, White - E767356 + E540494 (MTO) Customer Facing Display: 1002L: E155834, E324341 1302L: E683595, E683787 1502L: E125496 |
| Enclosure Color | Black |
| Touch Technology & Capacity | PCAP (TouchPro® Projected Capacitive) - 10 Touch |
| Processor | Qualcomm Snapdragon QCS6490 |
| Memory (RAM) | 8GB |
| Storage | 64GB |
| OS | Android 14 with Google Play Services (AOSP capable) Upgrade to Android 16 and planned upgrade to Android 18 are available with an OS 360 subscription |
| Diagonal Size | 10.1'' diagonal, Active matrix TFT LCD (LED) or 15.6'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 10": 16:10, 15": 16:9 |
| Active Area | 10": 8.54" x 5.34" / 217 mm x 136 mm 15": 13.55" x 7.62" / 344 mm x 194 mm |
| Resolution | 10": 1920 x 1200 @ 60Hz 15": 1920 x 1080 @ 60Hz |
| Number of Colors | 8-bit (16.7 million) |
| Brightness (Typical) | 10": LCD Panel: 450 nits, TouchPro PCAP: 387 nits 15": LCD Panel: 250 nits, TouchPro PCAP: 213 nits |
| Response Time-total (typical) | 30 msec |
| Contrast Ratio | 10": 900:1 15": 700:1 |
| Viewing Angle | 10": Horizontal: ±80° or 160° total / Vertical: ±80° or 160° total 15": Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total |
| I/O Ports | I-Series: USB 3.0 support (900mA) USB-C output* Micro SD slot GPIO RJ45 Ethernet LAN (Gigabit) DC input Z20 POS Stand for 10" I-Series: 1x DC-Input, 2x USB-A 3.0 (900mA) 1x RJ12 (Cash drawer) 12/24V 1x RJ45 Ethernet LAN (Gigabit) Z20 POS Stand for 15" I-Series: 1x DC-Input, 4x USB-A 3.0 (900mA) 1x RJ12 (Cash drawer) 12/24V 1x RJ45 Ethernet LAN (Gigabit)* 1x USB-C output - CFD (DisplayPort, Touch & Power Delivery)** *When using the standard 65W power brick, USB-C can support up to 15W. When using the optional 90W power brick, USB-C can support up to 27W. See User Manual for details. User will need to select the mode *Ethernet upload and download speeds may decrease to ~250Mbps when using the CFD USB speeds may be reduced to 2.0 speeds when DisplayPort video is being output. |
| Display Head Connection | DC Jack for Power USB-C for Data to the Z20 Stand IO Hub |
| Peripheral Mounting | 4x micro-USB 2.0 Elo Edge Connect ports Support for 1.2A on one port and 500mA for the remaining three ports |
| Webcam | 8MP, Max Resolution: 3200x2400 30fps, Auto Focus, Focus Range: >10cm |
| Wireless | 802.11a/b/g/n/ac/ax + Bluetooth 5.2 |
| Audio Ports | 2x built-in Digital Microphones |
| Speakers | 10-inch: 2x 2W 15-inch: 2x 1.5W |
| Power Supply | AC input voltage: 100-240 VAC Input frequency: 50-60 Hz |
| Power Consumption (Typical) | 10": On: 8.5W Off: 0.4W Sleep: 4.5W 15": On: 11.0W Off: 0.4W Sleep: 4.4W |
| Dimensions | 10" I-Series: 10" x 6.7" x 0.9" / 252.9 mm x 169.0 mm x 22.1 mm 10" Z20 POS Stand: 6.53" x 7.79" x 6.85" / 166 mm x 198 mm x 174 mm 15" I-Series: 15.34" x 9.8" x 0.9" / 389.7 mm x 249.7 mm x 22.3 mm 15" Z20 POS Stand: 7.6" x 10.0" x 6.7" / 194 mm x 255 mm x 169 mm |
| Shipping Box Dimensions | 10" I-Series: 12.6" x 6.0" x 9.8" / 320 mm x 150 mm x 250 mm 15" I-Series: 17.8" x 6.5" x 13.0" / 452 mm x 165 mm x 330 mm Z20 Stand: 12.36" x 11.93" x 12.4" / 314 mm x 303 mm x 315 mm |
| Weight (Unpackaged) | 10": 3.1 lbs / 1.4 kg 10" Z20 POS Stand: 6.6 lbs / 3.0 kg 15": 3.4 lbs / 1.6 kg 15" Z20 POS Stand: 8.1 lbs / 3.7 kg |
| Weight (Packaged) | 10": 7.9 lbs / 3.6 kg 10" Z20 POS Stand: 9.4 lbs / 4.3 kg 15": 10.6 lbs / 4.8 kg 15" Z20 POS Stand: 11.4 lbs / 5.2 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 50°C / -4°F to 122°F |
| Humidity | Operating: 20% to 80% Storage: 10% to 90% |
| Regulatory approvals and declarations | UL/cUL (US) FCC (US) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| Supported Countries | Canada, USA, Australia, Japan, New Zealand, Austria, Belgium, Czech Republic, Denmark, France, Germany, United Kingdom, Hungary, Italy, Netherlands, Poland, Portugal, Romania, Spain, Sweden, Switzerland, Turkey |
| Real-Time Clock | lithium coin cell battery |
| Hinge Life Rating | 5000 cycles |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | VESA 75mm |
| Warranty | 2-year |
| Extended Service Options | I-Series 5: 3 year OS 360 - Elo P/N: E897877 4 year OS 360 - Elo P/N: E898079 5 year OS 360 - Elo P/N: E898282 3 year Warranty Coverage – Elo P/N: E819394 4 year Warranty Coverage – Elo P/N: E819598 5 year Warranty Coverage – Elo P/N: E819795 3 year Warranty Coverage + ADP – Elo P/N: E130329 4 year Warranty Coverage + ADP – Elo P/N: E130530 5 year Warranty Coverage + ADP – Elo P/N: E130719 2 year Warranty Coverage + AUR – Elo P/N: E819985 3 year Warranty Coverage + AUR – Elo P/N: E820186 4 year Warranty Coverage + AUR – Elo P/N: E820388 5 year Warranty Coverage + AUR – Elo P/N: E820582 2 year Warranty Coverage + AUR + ADP – Elo P/N: E131490 3 year Warranty Coverage + AUR + ADP – Elo P/N: E131674 4 year Warranty Coverage + AUR + ADP – Elo P/N: E131859 5 year Warranty Coverage + AUR + ADP – Elo P/N: E132053 Z20 POS Stand: 3 year warranty coverage - Elo P/N: E375367 4 year warranty coverage - Elo P/N: E375573 5 year warranty coverage - Elo P/N: E375771 2 year warranty coverage + AUR - Elo P/N: E375970 3 year warranty coverage + AUR - Elo P/N: E376169 4 year warranty coverage + AUR - Elo P/N: E376362 5 year warranty coverage + AUR - Elo P/N: E376547 |
| OS Support | Bi-monthly Android security updates available with Elo OS 360 package. |
| Sealability | Touchscreen sealed to LCD |
| What's in the Box | I-Series 5 I-Series 5 North American Power Cable European Power Cable Power Brick Quick Install Guide Screws for cable cover door Tie wrap 10" Z20 POS Stand Z20 POS Stand for 10" I-Series North American Power Cable European Power Cable Quick Install Guide 90W Power Brick VESA cover, top 10" (for mounting to the hinge) VESA cover, bottom 10" (for mounting to the hinge) Base Plate (for mounting to a countertop) Cable Tie (for securing cables) 1x Screw, M4x6 (in Bag “A” - for mounting VESA covers) 4x Screw, M4X8 (in Bag “B” - for mounting main display) 1x Screw, M3X6 (in Bag “C” - for mounting base plate) 15" Z20 POS Stand Z20 POS Stand for 15" I-Series North American Power Cable European Power Cable Quick Install Guide; 150W Power Brick 0.3m USB-C to USB-C Cable (To provide USB and Video signals to the CFD) VESA Cover, Top 15" (for mounting to the hinge) VESA Cover, Bottom 15" (for mounting to the hinge) Base Plate (for mounting to a countertop) CFD Cover (for mounting a customer-facing display) Cable Tie (for securing cables) 1x Screw, M4x6 (in Bag “A” - for mounting VESA covers) 1x Screw, M4x6 (in Bag “A” - for mounting base plate) 4x Screw, M4X8 (in Bag “B” - for mounting main display) 4x Screw, M4X20 (in Bag “C” - for mounting a customer-facing display) |
| Optional Peripherals | Magnetic Stripe Reader (MSR) – Elo P/N: E001002 Fingerprint Scanner – Elo P/N: E134286 2D Barcode Scanner (Black - SE2707) – Elo P/N: E393160 2D Barcode Scanner (Black - SE4720) – Elo P/N: E384627 2D Barcode Scanner (Black - SE4107) – Elo P/N: E245047 Status Light (Micro-USB Connectivity) - Elo P/N: E644767 Webcam - Elo P/N: E201494 RFID - Elo P/N: E673037 |
| Stands, Mounts & Kits | 150W Replacement Cable Kit (NA & EU power cables and 150W power brick) – Elo P/N: E792273 1002L - Elo P/N: E155834 1002L - Elo P/N: E324341 1302L - Elo P/N: E683595 1502L - Elo P/N: E125496 |
Create your perfect POS system.
Built on Elo’s unified architecture, the EloPOS Z30 delivers a powerful point of sale system that outperforms the competition. Complete with a 15.6-inch Full HD interactive display, integrated connectivity hub, contained cable routing, optional customer-facing touchscreen display and Android 14 OS, the EloPOS Z30 brings one of the sleekest form factors to the market.
 |  |  |
| Compatible with the 15‑inch I‑Series Slate | Compatible with the 10‑ & 15‑inch I‑Series 4&5 | Compatible with the 15‑inch I‑Series Slate |
| I/O | ||
|
|
|
| Secondary Display | ||
| Optional 7-inch CFD. | Optional 10‑, 13‑ or 15‑inch CFD. | Choose integrated CFD; or no CFD in stand. |
