EloPOS Z30
15.6" Full HD Android POS System with integrated CFD; or no CFD in stand.
- Compact form factor: Purposefully architected to fit everything you need at the point of sale into a sleek compact design.
- Powerful Touchscreen: The EloPOS Z10 offers a fully integrated 15.6-inch full HD interactive display.
- Interactive display for customers: Offer your customers a point of interaction to review transactions, participate in loyalty programs and see the latest promotions with the customer-facing touchscreen display.
Datasheet
Product Specification
| Part Number(s) | EloPOS Z30 Standard Model with CFD: E482347 EloPOS Z30 Value Model with CFD: E482746 EloPOS Z30 Standard Model without CFD: E392186 EloPOS Z30 Value Model without CFD: E392977 |
| Enclosure Color | Dark Gray Metallic |
| Touch Technology & Capacity | PCAP (TouchPro® Projected Capacitive) - 10 Touch |
| Processor | Standard Model: Qualcomm Snapdragon SDA660 Value Model: Rockchip RK3399 |
| Memory (RAM) | 4GB |
| Storage | Standard Model: 64GB Value Model: 32GB |
| OS | Android 10 with Google Play Services and EloView content deployment and management |
| Diagonal Size | 15.6'' diagonal, Active matrix TFT LCD (LED) |
| Aspect Ratio | 16:9 |
| Active Area | 13.55" x 7.62" / 344 mm x 194 mm |
| Resolution | 1920 x 1080 @ 60Hz |
| Number of Colors | 8-bit (16.7 million) |
| Brightness (typical) | Standard Model: LCD Panel: 350 nits TouchPro PCAP: 280 nits Value Model: LCD Panel: 350 nits TouchPro PCAP: 280 nits |
| Response Time-total (typical) | 20 ms |
| Contrast Ratio | 1000:1 |
| Viewing Angle | Horizontal: ±85° or 170° total / Vertical: ±85° or 170° total |
| I/O Ports | DC Input 4 x USB-A 3.0 (900mA) RJ45 Ethernet LAN (Gigabit) RJ12 (Serial/cash drawer)* 12/24V - User will need to select mode Powered USB 24V USB-C output - CFD (DisplayPort, touch and power delivery up to 27W) |
| Integrated Customer-Facing Display | Size -10.1 inch Resolution - 1280 x 800 @ 60 Hz Active Display Area (H x V) - 8.7" x 5.3" / 216.96 mm x 135.6 mm Viewing Angle - Horizontal: ±80° or 160° total / Vertical: ±80° or 160° total Brightness - LCD Panel: 400 nits, TouchPro PCAP: 344 nits Number of Colors - 8-bit (16.7M) Touch Technology - TouchPro PCAP Sealing - Touchscreen sealed to LCD Number of Touches - 10 |
| Webcam | 5MP Max Resolution: 1920x1080 30fps Auto Focus |
| Wireless | 802.11a/b/g/n/ac + Bluetooth 5.0 |
| Audio Ports | Standard Model: 2x built-in Digital Microphones Value Model: 1x built-in Analog Microphone |
| Speakers | Standard Model: 2x 0.7W Value Model: 2x 1W |
| Power Supply | AC input voltage: 100-240 VAC Input frequency: 50-60 Hz |
| Power Consumption (Typical) | Standard Model wIth CFD: On: 18W; Off: < 0.5W; Sleep: 13W Value Model wIth CFD: On: 17.84W; Off: < 0.7W; Sleep: 12.9W Standard Model wIthout CFD: On: 12W; Off: < 0.5W; Sleep: 7W Value Model wIthout CFD: On: 11.8W; Off: < 0.7W; Sleep: 7.66W |
| Dimensions | 11.6" x 7.4" x 14.6" / 294 mm x 188 mm x 371 mm |
| Shipping Box Dimensions | 18.22" x 11.22" x 17.64" / 463 mm x 285 x 448 mm |
| Weight (Unpackaged) | 9.6 lbs / 4.4 kg |
| Weight (Packaged) | 17.1 lbs / 7.75 kg |
| Operating Temperature | 0°C to 40°C / 32°F to 104°F |
| Storage Temperature | -20°C to 50°C / -4°F to 122°F |
| Humidity | Operating: 20% to 80% Storage: 5% to 95% |
| Regulatory approvals and declarations | UL/cUL (US) FCC (US) Class B (CFD Version is Class A only) IC (Canada) CE (Europe) CB (International) VCCI, MIC (Japan) RCM (Australia) |
| Supported Countries | Canada, USA, Australia, Japan, New Zealand, Austria, Belgium, Czech Republic, Denmark, France, Germany, United Kingdom, Hungary, Italy, Netherlands, Poland, Portugal, Romania, Spain, Sweden, Switzerland, Turkey |
| Real-Time Clock | lithium coin cell battery |
| MTBF | 50,000 hours demonstrated |
| Mounting Options | VESA 75mm |
| OS Support | Complimentary security updates provided for the first three months. Optional extended coverage available with Elo OS 360 package. |
| Sealability | Standard Model: Touchscreen optically bonded to LCD Value Model: Touchscreen sealed to LCD |
| What's in the Box | EloPOS Z30 North American Power Cable European Power Cable Quick Install Guide 150W Power Brick 2 x Zip Ties 1 x M4x8 mm screw in a plastic bag 1 x M3x6 mm screw in a plastic bag Base Plate – for mounting to a countertop |
| Stands, Mounts & Kits | 0702L - Elo P/N: E796382 1002L - Elo P/N: E155834 1002L - Elo P/N: E324341 1302L - Elo P/N: E683595 1502L - Elo P/N: E125496 |
Create your perfect POS system.
Built on Elo’s unified architecture, the EloPOS Z30 delivers a powerful point of sale system that outperforms the competition. Complete with a 15.6-inch Full HD interactive display, integrated connectivity hub, contained cable routing, optional customer-facing touchscreen display and Android 10 OS, the EloPOS Z30 brings one of the sleekest form factors to the market.
 |  |  |
| Compatible with the 15‑inch I‑Series Slate | Compatible with the 10‑ & 15‑inch I‑Series 4 | Compatible with the 15‑inch I‑Series Slate |
| I/O | ||
|
|
|
| Secondary Display | ||
| Optional 7-inch CFD. | Optional 10‑, 13‑ or 15‑inch CFD. | Choose integrated CFD; or no CFD in stand. |
