ID-EGUC-F4S3
Module Type: M.2 2280 to Four Isolated CAN FD Module, Function: CAN Bus
Provides
- Baud rate up to 5 / 10 / 20 / 50 / 100 / 125 / 250 / 500 (default) / 800 / 1000K
- CAN2.0 up to 7,800 frame/s (RX baud rate 1M, EID, 8byte data)
- CANFD up to 6,000 frame/s (RX baud rate 1M, data rate 5M, EID, 64byte data)
- Data rate supports 2 / 4 / 5Mbps
Features
- Complies with IEC 60950-1 : 2005 + A1 : 2009 + A2 : 2013 2.5kV HiPOT protection
- Complaint with EN61000-4-2 (ESD) Air-15kV, Contact-8kV
- Termination resistor enabled / disabled by jumper
- Additional driver to support Linux SocketCAN
Datasheet
Product Specification
Model Name | EGUC-F4S3 |
| Module Type | M.2 2280 to Four Isolated CAN FD |
| Form Factor | M.2 2280 B+M Key |
| Function | CAN FD |
| Input I/F | USB 2.0 High Speed (480Mbps) |
| Output I/F | CAN FD |
| Output Port | 4 |
| Output Connector | DB-9 |
| Max. Power Consumption | 2.894W (3.3V, 877mA) |
| Dimension (W x L x H/mm) | 22 x 80 x 12.65 |
| Temperature | Operation : W/T -40°C ~ 85°C (Ta) Storage : -55°C ~ 95°C (Ta) |
| Vibration | 5G@[7~2000Hz] |
| Shock | 50G@0.5ms |
| OS Support | Windows : 10 (32 / 64bit) and above version Linux : Kernel 2.6 and above (Native CDC-ACM driver), Kernel 2.6.38 and above (SocketCAN Driver), 32 / 64bit |
BORN FOR SUPERIOR PERFORMANCE
The EGUC-F4S3 is an M.2 CAN FD module compliant with ISO 11898-2 : 2016, supporting baud rates from 5 Kbps to 1 Mbps and data rates up to 5 Mbps. It can handle up to 7,800 frames per second for CAN 2.0 and 6,000 frames per second for CAN FD. Key features include a CAN message acceptance filter, listen-only mode, and configuration retention after reboot.
The module includes additional drivers for Linux SocketCAN and offers termination resistor control via a jumper. It complies with 2.5 kV HiPOT protection and EN61000-4-2 ESD standards.
Designed for industrial use, it operates within a temperature range of -40°C to 85°C, features a 30µ” golden finger, and comes with a 3-year warranty.
Ordering Information
| P/N | Description |
| EGUC-F4S3-W1 | M.2 2280 to Four Isolated CAN FD Module |
CAN Bus series combines the advantages of CAN 2.0 and CAN FD, effectively meeting industrial communication needs. CAN 2.0 supports J1939 and CANopen protocols, providing a stable solution for standard communication, while CAN FD offers high-speed transmission and enhanced data processing to accelerate the development of emerging applications. The entire product line features 2.5kV voltage isolation protection, operates within industrial-grade temperature ranging from -40°C to 85°C, and includes Linux SocketCAN drivers, simplifying system integration and enhancing performance reliability.
| Series | EGPC (M.2 to PCIe CAN) | EGUC (M.2 to USB CAN) | EMUC (mPCIe to USB CAN) | EMPC (mPCIe to PCIe CAN) | ESPC (PCIe to PCIe CAN) |
| Form Factor | M.2 2242 / 2260 / 2280 | M.2 2242 / 2260 / 2280 | mPCIe | mPCIe | PCIe |
| Isolation (2.5kV) | Yes | Yes | Yes | Yes | Yes |
| Output CAN | 1 / 2 / 4 | 1 / 2 / 4 | 2 | 2 / 4 / 6 / 8 | 2 / 4 / 6 / 8 |
| CAN FD | Yes | Yes | Yes | Yes | Yes |
| High Layer Protocol | J1939 / CANopen | J1939 / CANopen | J1939 / CANopen | J1939 / CANopen |
